Non-Invasive Temperature Transmitter


Rail-mount temperature transmitters

Non-invasive temperature transmitters

Non-Invasive temperature transmitter TSP341-N

A simpler and safer approach.

SAFER and no risk of thermowell breaking off

REDUCED COST Quick to install for less costly installation No thermowell testing, calculations or need for exotic materials

HIGH PERFORMANCE Keep your measurement quality

SIMPLER Straightforward from ordering to maintenance No thermowell stocking

TSP341-N – A simpler and safer way of measuring your process temperature without the need to shut down, drill a hole or install a thermowell.

With its innovative double sensor architecture and specially developed calculation algorithm, it greatly enhances your safety and reduces your installation costs without sacrificing the quality of your measurement.

  • Process connection
    • Surface mounting to vessels and piping (Clamp-on concept)
  • Sensor
    • Thin film resistor Pt100 in three-wire circuit; nickel tip
  • Material connection heads
    • Aluminum, epoxy-coated or stainless steel
  • Communication
    • 4 to 20 mA, HART 7
  • Accuracy
    • Similar to invasive sensor under common conditions
  • Response time
    • Matches or exceeds invasive sensor performance
  • Measuring range (surface temperature)
    • –40 to 400 °C (–40 to 752 °F)
  • Transport/storage temperature
    • –20 to 70 °C (–4 bis 158 °F)
  • Ambient temperature range at connection head
  • Without LCD indicator: –40 to 85 °C (–40 to 185 °F)
  • With LCD indicator: –20 to 70 °C (–4 to 158 °F)
  • IP rating
    • IP 66 / IP 67
  • Vibration resistance
    • 10 to 58 Hz: 0,075 mm (0,003 in.) > 58 to 2000 Hz: 10 m/s2 (1 g)
  • Explosion protection
    • Global approvals; intrinsic safety and flameproof enclosure
