Thermal mass flowmeter

Thermal mass flowmeter

SensyMaster FMT200

The SensyMaster FMT230 offers a high quality and cost effective solution for precise and dynamic direct mass flow measurements of gases in low and medium pressure conditions. The model comes preconfigured for the application, ready to be installed by OEM customers.

The FMT250 adds high accuracy and extended functionality for advanced applications.

SensyMaster’s concept comprises high grade thermal sensor elements with superior long-term stability, the ABB platform based electronics with comprehensive signal evaluation capabilities for a high degree of performance and reliability. The software offers the ApplicationSelector that allows to change application parameters and create new applications on site and VeriMass the fingerprint based thermal sensor element verification function.

Both models communicate via MODBUS Interface and follow the SmartSensor concept. The SensyMaster FMT230 is ideally suited for all OEM applications, the FMT250 for advanced OEM application.


Thermal mass flowmeter

Thermal mass flowmeter

SensyMaster FMT400

The SensyMaster FMT430 offers a high quality and cost effective solution for precise and dynamic direct mass flow measurements of gases in low and medium pressure conditions to meet the needs of all industrial standard applications.

The FMT450 adds high accuracy and extended functionality for advanced industrial applications. SensyMaster’s concept comprises high grade thermal sensor elements with superior long-term stability, the common ABB look and feel with ABB specific menu structures and through-the-glass-operation and the ABB platform based electronics with comprehensive signal evaluation capabilities for a high degree of performance and reliability. The software offers the ApplicationSelector that allows to change application parameters and create new applications on site and VeriMass the fingerprint based thermal sensor element verification function.

Both integral and remote mount design is available with or without local display and HART communication supporting the modular I/O and the SmartSensor concept. Both models offer easy to understand diagnostic messages for improved operator efficiency.

The SensyMaster FMT430 is ideally suited for all industrial standard applications, the FMT450 for advanced industrial application.


Thermal mass flowmeter

Thermal mass flowmeter

Sensyflow FMT200-ECO2

The ELECTRA-flo/CM Thermal Airflow Measuring Station combines thermal dispersion measurement technology with an integral honeycomb cell air straightener to assure measurement accuracy within ±2-3%. The addition of the honeycomb cell air straightener is vital to obtain these degrees of Sensyflow FMT200-ECO2 is a very compact and highly dynamic mass flowmeter for air. It offers a direct mass or standard volume flow measurement in pneumatic applications, e. g. in paint robot control or compressed air systems.

The Sensyflow FMT200-ECO2 consists of an easy to install pipe component which accommodates the sensor unit and the evaluation electronics. It directly provides a linearized output signal, and it is calibrated and immediately ready for use.

A standard RS 232 interface allows the change over between the individual output signals (current, voltage, frequrency, pulse and alarm) and to configure the device.

Due to its flexible connection concept this measuring instrument can be installed in pipes or tubes of different types and sizes. Various process adapters are available for this purpose.

A standard power supply unit can be used for powering the FMT200-ECO2.


Thermal mass flowmeter

Thermal mass flowmeter

Sensyflow FMT700-P and FMT700-P Compact

Sensyflow FMT700-P is for direct mass flow measurement of air. The measurement is independent of operating pressure and temperature. It supplies best accuracy together with an unrivalled response time. Used in quality assurance, test bench applications, research and development. It is the reference system for intake air measurement of the leading car manufacturers worldwide.

The measuring system comprises a flowmeter sensor (measuring tube), a measuring section and a supply / evaluation unit. The FMT700-P Compact has an integrated transmitter.

The sensor is designed as a measuring tube and accommodates the measuring elements. The meter tube is available in six nominal diameters ranging from DN 25 to DN 200 and is installed in the measuring section by using quick-clamping connectors.

The measuring section consists of inlet and outlet sections of the appropriate size and of an air filter or flow conditioner which can be connected – e.g. to an air duct – via the connection piece on the suction side.

The Sensyflow FMT700-P Compact can simultaneously operate one analog output (current 0 / 4 to 20 mA or voltage 0 to 5 / 10 V), one digital output (frequency, pulse, alarm) and a serial RS232 interface.


Thermal mass flowmeter

Thermal mass flowmeter

Series 8600-8700MP Inline Thermal Mass Flow Meter

This series meter is great for where agency approvals are required for Explosion Proof area locations. See specifications.

Inline style thermal mass flow meters include a flow section that is usually specified to match the user’s flow conduit and is then plumbed directly into the process line. This design has the sensing elements mounted directly in the flow section for exposure to the process gas. Our inline style thermal mass flow meters are available in sizes from 1/4″ pipe through 4″ pipe or tube, and are provided with a variety of options such as MNPT ends, tube end fittings, butt weld ends, flanged end configurations, etc. as required. Pipe sizes in excess of 4″ typically require insertion style thermal mass flow meters.


Thermal mass flowmeter

Thermal mass flowmeter

Series 8600-8700MPNH Inline Thermal Mass Flow Meter

Certified to CSA/CUS Standards: Class 2252-03 & 2252-83 for Process Control Equipment in Ordinary Locations Only; CSA Enclosures Type 4X, IP66;

Inline style thermal mass flow meters include a flow section that is usually specified to match the user’s flow conduit and is then plumbed directly into the process line. This design has the sensing elements mounted directly in the flow section for exposure to the process gas. Our inline style thermal mass flow meters are available in sizes from 1/4″ pipe through 4″ pipe or tube, and are provided with a variety of options such as MNPT ends, tube end fittings, butt weld ends, flanged end configurations, etc. as required. Pipe sizes in excess of 4″ typically require insertion style thermal mass flow meters.


Thermal mass flowmeter

Thermal mass flowmeter

Series 9100MP Inline Remote Flow Averaging Tube (FAT)

Inline style thermal mass flow meters include a flow section that is usually specified to match the user’s flow conduit and is then plumbed directly into the process line. This design has the sensing elements mounted directly on the flow section for exposure to the process gas. Our inline style flow averaging thermal mass flow meters are available in sizes from 2″ pipe through 4″ pipe and are provided with flanged end configurations, as required. Pipe sizes in excess of 4″ typically require insertion style thermal mass flow meters.


Thermal mass flowmeter

Thermal mass flowmeter

ValuMass™ 500 Inline Thermal Mass Flow Meter

Series 500 ValuMass™ flow meters offer a lower cost option for many flow applications with the high value associated with all of EPI’s flow measurement instrumentation.

Eldridge Products, Inc. has achieved innovation and excellence in thermal dispersion gas mass flow measurement since 1988. With an economical set of features and a number of common configuration and installation choices, our newest ValuMass™ flow meters continue our tradition of solving flow measurement challenges for customers around the world.

ValuMass™ Series 500 Flow meters

Eldridge Products, Inc. (EPI) is a proven leader in gas flow measurement. Our Master-Touch™ thermal dispersion gas mass flow meters and patented Flow Averaging Tubes set the standard for innovation, performance and reliability. Now our Series 500 ValuMass™ flow meters offer a lower cost option for many flow applications with the high value associated with all of EPI’s flow measurement instrumentation.


Thermal mass flowmeter

Thermal mass flowmeter

Series 9000MP Multipoint Thermal Mass Flow Meter

Multipoint Systems are designed to measure gas flows where two or more sensing points are required due to large cross-sectional areas, such as large air intake ducts or air exhaust and flue stacks. These systems can have up to 5 sensors on each probe. Our System Control Panel (SCP) will average all sensors from all probes. Many probes can be connected to one SCP.

Multipoint Systems are designed to measure gas flows where two or more sensing points are required due to large cross-sectional areas, such as large air intake ducts or air exhaust and flue stacks. Our Series 9000MP Multipoint Systems are installed throughout the world, providing our customers with years of steady, reliable service. Coupled with our new Air Purge System, the Series 9000MP Multipoint Systems are now well-suited to an even greater variety of industrial applications. The probe design supports applications as diverse as ambient air flows in HVAC ducts, exhaust gas in large diameter stacks, boiler NOx efficiency systems and municipal waste incinerators. Our customers include environmental/HVAC system integrators, pulp & paper mills, power & energy companies, etc. across the US, Europe and Asia. The configuration and installation options support facility retrofits as well as the most modern new construction requirements.


Thermal mass flowmeter

Thermal mass flowmeter

Thermal Mass Flow Meter

F-5400

The F-5400 is a blind (no display) version of our thermal mass flow meter that is available as an inline or insertion style meter, and provides both an analog (4-20mA) output for flow rate and a scaled pulse output for totalization.

Proprietary digital control sensing circuitry is very stable and yet responsive to changes in flow. This design allows for accurate flow measurement over a very wide operating range (over 1000:1 for the inline version). It also makes the meter ideal for measuring low flow rates. Each meter is individually calibrated and is accurate to within ± 1.0% of reading for standard natural gas applications.


Thermal mass flowmeter

Thermal mass flowmeter

Thermal Mass Flow Meter

F-5500

F-5500 Thermal Mass Flow Meters provide direct standard volumetric flow measurement of gases without the need for temperature and pressure compensation. Both inline and insertion versions of the flow meter are available. The insertion design allows for easy insertion or removal from the pipe without the use of special tools and without disrupting flow. Inline meters are ideal for pipes less than 1½" in diameter. The low maintenance design is provided ready-to-use without the need for field programming.

The F-5500 flow meter includes a bright, easy-to-read user interface/display that provides rate and total data. The standard version of the meter is provided with a 4-20 mA analog output and an RS485 interface that is field configurable for BACnet® MS/TP or Modbus® RTU. A second output signal configuration is available that includes a 4-20 mA output for flow rate and a scaled pulse output for totalization or alarm indication.

Proprietary digital control sensing circuitry is very stable and yet responsive to changes in flow. This design allows for accurate flow measurement over a very wide operating range (over 1000:1 for the inline version). It also makes the meter ideal for measuring low flow rates. Each meter is individually calibrated and is accurate to within ± 1.0% of reading for standard natural gas applications.
